Lock and unlock your home without the hassle of keys. Create unique PIN codes to share with your family and friends for ultimate convenience.
Including a backlit touch screen keypad, users have the option of entering a PIN code to unlock the door.
An automatic re-lock function is available so that when the latch is retracted, the lock will automatically lock after a specified period of time.
The Yale Assure Lock digital deadbolt can be upgraded with a Yale module (Yale Access, Z-Wave Plus* and ZigBee*) to seamlessly integrate into most home automation and alarm systems.
*Modules are sold separately
Ā
Product FeaturesĀ
Ā
|
Ā |
Create Unique Pin Codes Ā |
|
Ā |
Touchscreen Keypad Ā |
|
Ā |
Key override Ā |
|
Ā |
Tamper Alarm Ā |
|
Ā |
Retrofit Replace your mechanical deadbolt with the Yale Assure digital lock. Ā |
|
Ā |
Simple InstallationĀ Ā |
Ā
Ā
Product Specifications
Ā
Ā
|
Backset: Ā Ā |
Adjustable 60-70mm Ā Ā |
|
Battery type: Ā Ā |
AA Ā Ā |
|
Body / Case Material Ā Ā |
Zinc Ā Ā |
|
Bolt Type / Function Ā Ā |
Deadbolt Ā Ā |
|
Door Thickness Range Ā Ā |
35mm to 50mm Ā Ā |
|
Door Preparation Ā Ā |
25mm latch hole and 54mm lock hole Ā Ā |
|
Lock Type Ā Ā |
Deadbolt Ā Ā |
|
Standard Finish Ā Ā |
Satin Chrome Ā Ā |
|
Warranty / Guarantee Ā Ā |
Yale 1 year Electromechanical Ā Ā |
|
Key Profile (Keyed version) Ā Ā |
C4 Ā Ā |
|
Operational Temperature Range Ā Ā |
-25C to 60C Ā Ā |
|
Operating Humidity Ā Ā |
up to 95% Ā Ā |
|
Approvals Ā Ā |
RCM Compliant (EN 61000.6.3 2012 & EN 55032 2016) Ā Ā |
Dimensions
Ā
Ā
Yale Assure Lockā¢Ā (Keyed version)
Ā
Ā
Ā
Ā
Products Supplied in Box
Ā
Ā
-
Yale Assure Lockā¢
Ā
-
Installation Guide
Ā
-
Mounting Screws
Ā
-
Door Template
Ā
-
4 AA Batteries
Ā
-
Plastic Gasket
